Gauge 6 Dial Size MNPT Connection MPN:PFP2326WBY
Gauge 6 Dial Size MNPT Connection
Buy Winters item #PFP2326WBY to have a positive impact 📈 on our community of Service Disabled Veteran-Owned Business partners.
Technical Specifications
- Item Vacuum Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 6 in
- Basic Gauge Case Material Stainless Steel
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/2 in
- Gauge Connection Location Bottom
- Gauge Primary Range Values -30 to 0
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Vacuum Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Case Material 304 Stainless Steel
- Gauge Case Color Gray
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material Stainless Steel
- Gauge Lens Material Polycarbonate
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -4 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Characteristics Protects Against Vibration and Pulsation
- For Use With Compressors, Hydraulic and Oil Field Equipment, Process Industries, Pumps
- Calibration Certificate Included No
- Series PFP
- Includes Bayonet Ring, Liquid Filled Case, Reflective Fluorescent Yellow Dial, Restrictor Screw
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PFP2326WBY
- MPN: PFP2326WBY
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112406
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Vacuum gauges
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:33am UTC
Category: Pressure and Vacuum Measuring
