Pressure Gauge 2 Dial Size Black MPN:PEM1408-CD
SKU
226-CXO-491F97
Pressure Gauge 2 Dial Size Black
Monitor pressure within your system with ease through this pressure gauge that displays a large 2-inch dial size enabling clear viewing from distance - featuring an accuracy of 1.5%, it ensures precise readings while constructed with durability in mind; its 0-300 psi range allows usage for variety of systems such as hydraulics or pneumatics making it ideal within industrial settings.
Buy Winters item #PEM1408-CD to have a positive impact 📈 on our community of Service Disabled Veteran-Owned Business partners.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/8 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 160
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 1100
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 10/100
- Gauge Case Material Steel
- Gauge Primary Range Numbered Graduations 20/200
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Acrylic
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series PEM
- Manufacturers Warranty Length 5 yr
- Features Black Dial, Red Bar Scale/Pointer, White psi Scale
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PEM1408CD
- MPN: PEM1408-CD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:46am UTC
Category: Pressure and Vacuum Measuring
