K4539 Pressure Gauge 2 Dial Size Silver MPN:PFQ2438-DRY-2FF
SKU
226-CXO-491F71
K4539 Pressure Gauge 2 Dial Size Silver
K4539 Pressure Gauge 2 Dial Size Silver offers precision measurements with dual scaling of pressure displayed in both PSI (Pounds per Square Inch) and bar units to facilitate conversion. The stainless steel material construction adds durability while the protective bezel guard guards against any harm during storage or transit. Its rangeability extends from 0-600 PSI and -1 to 250 bar, suitable for diverse applications in various fields. As a versatile tool, this gauge finds its utility across domains including HVAC systems, gas pressure regulation, laboratory experiments, hydraulics, pneumatics, manufacturing, refrigeration and air compressors among others making it a valuable asset for professionals needing accurate measurements.
Buy Winters item #PFQ2438-DRY-2FF to have a positive impact 📈 on our community of Service Disabled Veteran-Owned Business partners.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/8 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 160
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 1100
- Gauge Accuracy +/-2.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method Front Flange
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 10/100
- Gauge Case Material 304 Stainless Steel
- Gauge Primary Range Numbered Graduations 20/200
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Acrylic
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 200 Degrees F
- Gauge Special Options Heavy Duty
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series PFQ
- Manufacturers Warranty Length 5 yr
- Features Ring Terminal
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PFQ2438DRY2FF
- MPN: PFQ2438-DRY-2FF
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B0087UCI8C, B0087UBIM4, B0087UDAB6
Product info last updated on September 26, 2024 1:02pm UTC Category: Pressure and Vacuum Measuring
