K4215 Pressure Gauge 4 Dial Size Black MPN:PCC607C
The K4215 pressure gauge is an essential tool for any industry where precise measurement of pressure levels are necessary. This all-stainless steel device ensures reliability and durability in tough environments, making it perfect for manufacturing processes or power plants that require steady pressure monitoring. Its 4 dial size makes readings easily accessible, while the gauge's ability to rotate freely allows for accurate measurements in both directions. Additionally, this versatile gauge can be used on liquid or gas systems, making it an ideal choice for various industrial applications. Finally, its compact design and compatibility with standard installation methods make the K4215 a must-have addition to any facility's maintenance equipment inventory!
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 4 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 300
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 2100
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 10/100
- Gauge Case Material Plastic
- Gauge Primary Range Numbered Graduations 50/200
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Polycarbonate
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 200 Degrees F
- Gauge Special Options IP65 Protection Rating
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series PCC
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PCC607C
- MPN: PCC607C
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
