K4215 Pressure Gauge 4 Dial Size Black MPN:PCC601C
The K4215 pressure gauge is a stainless steel, black diaphragm pressure gauges designed for reliable measurements in the most demanding environments. It features an analogue mechanical dial with 360 rotational visibility and displays up to 200 PSI (pounds per square inch) measuring pressure range within increments of 5%, providing users an accurate readout of system's performance. The gauge can be used in hydraulic, pneumatic or water systems where high precision and reliable pressure indication is required; suitable applications include but not limited to industrial machinery, manufacturing processes, power plants or any other facility which relies on steady pressure monitoring. Its 4 dial size allows easy visibility while mounted in tight spaces - including panel installation without the need for additional adapters or conversion kits ensuring consistent performance even under extreme conditions!
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 4 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 15
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 100
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 1/5
- Gauge Case Material Plastic
- Gauge Primary Range Numbered Graduations 3/10
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Polycarbonate
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 200 Degrees F
- Gauge Special Options IP65 Protection Rating
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series PCC
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PCC601C
- MPN: PCC601C
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
