Compound Gauge 4 Dial Size Silver MPN:PFQ1262
This high precision 4 dial gauge offers an accurate and easy to read measurement scale that ranges from 0-15 inches with graduation of 0.001 inch resolution. The chrome-plated case and brass housing provide durability, while the silver finish provides excellent visibility on the dial face ensuring precise readings even in low light conditions. This dial gauge is ideal for calibration and testing applications in hydraulic systems or automotive industries where accurate pressure measurement are critical to achieving optimal performance. The compact design of this gauge allows easy access to tight locations and its stainless steel extension and hose fitting ensures a reliable connection that reduces leaks and contamination risk. With its exceptional durability, accuracy and versatility, the Compound Gauge 4 Dial Size Silver is an essential tool in any commercial or industrial pressure measurement system.
Technical Specifications
- Item Compound Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 4 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values -30 to 0 to 30
- Gauge Secondary Range Units gpm
- Gauge Secondary Range Values 0 to 70,000
- Gauge Accuracy +/-1.50%
- Pressure and Vacuum Gauge Type Compound Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 10/5/10
- Gauge Case Material 304 Stainless Steel
- Gauge Primary Range Numbered Graduations 10/10/50
- Gauge Case Color Stainless Steel
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material Stainless Steel
- Gauge Lens Material Polycarbonate
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -4 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- For Use With Media Compatible with 316L Stainless Steel
- Calibration Certificate Included No
- Series PFQ
- Manufacturers Warranty Length 5 yr
- Features Ring Terminal
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PFQ1262
- MPN: PFQ1262
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
