K4520 Pressure Gauge 2-1/2 Dial Size Black MPN:P9U901453UC
SKU
226-CXO-491D63
K4520 Pressure Gauge 2-1/2 Dial Size Black
K449502, Ball end mill offers precise and accurate cutting for various materials such as aluminum, copper or stainless steel with its solid carbide construction offering durability and longevity while avoiding cracks and fractures in its 4 flutes. The 0.071in Dia shank is capable of drilling or milling various pockets' corner making it the perfect tool for professionals requiring precision cuts for plastic machining. Its LOC 0.213in reduces the deflection and enables the user to have better contact with the workpiece surface increasing precision without sacrificing surface finish quality.
Buy Winters item #P9U901453UC to have a positive impact 📈 on our community of Service Disabled Veteran-Owned Business partners.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 400
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 2800
- Gauge Accuracy +/-2-1-2%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method U Clamp
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 50/100
- Gauge Case Material Steel
- Gauge Primary Range Numbered Graduations 100/500
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Acrylic
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Zero Adjustment Screw
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series P9U
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: P9U901453UC
- MPN: P9U901453UC
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
