K4562 Pressure Gauge 2 Dial Size Brass MPN:PWL2720
SKU
226-CXO-491D43
K4562 Pressure Gauge 2 Dial Size Brass
Ensure your facility's safety with our polycarbonate cutting tool machine guard and shield designed to adhere to OSHA guidelines while being easy to install via screws or adhesive alternatives - perfect for industries like manufacturing, construction, and metalworking plants. This durable option simplifies installation method without compromise! Trust our reliable product now.
Get Winters item #PWL2720 from our selection of Measuring Tools & Sensors while supporting Veterans 🎖.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Welding Regulator
- Gauge Nominal Dial Size 2 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 30
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 200
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 1/10
- Gauge Case Material Brass
- Gauge Primary Range Numbered Graduations 5/50
- Gauge Case Color Gold
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Polycarbonate
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series PWL
- Manufacturers Warranty Length 5 yr
- Features Non Sparking Materials
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PWL2720
- MPN: PWL2720
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Compressed Gas Dial Pressure Gauges
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:40am UTC
Category: Pressure and Vacuum Measuring
