Pressure Gauge 4-1/2 Dial Size Black MPN:PPC5070-SG45
Pressure Gauge 4-1/2 Dial Size Black
The K4526 Pressure Gauge 4-1/2 Dial Size Black is a precise pressure measurement tool designed for professionals who require accurate readings of gas or liquid pressure within its 0 to 500 psig (3448 kPa) range. Made from durable stainless steel, it offers superior resistance to corrosion and provides reliable measurements for various applications including air compressors, hydraulic systems, pneumatic systems, and more. With an easy-to-read dial face, the gauge is perfect for those who need to monitor pressure levels in their work. The K4526 can be mounted on a panel or wall with the included bracket, making it an essential tool for professionals in diverse industries who demand precise and reliable pressure measurements.
Get Winters item #PPC5070-SG45 from our selection of Measuring Tools & Sensors while supporting Veterans 🎖.
Technical Specifications
- Item Pressure Gauge
- Gauge Application Process
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Stainless Steel
- Gauge Connection Type MNPT
- Gauge Connection Size 1/2 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 1000
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 7000
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method Surface
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 50/500
- Gauge Case Material Phenolic
- Gauge Primary Range Numbered Graduations 100/1000
- Gauge Case Color Black
- Basic Gauge Socket Material Stainless Steel
- Gauge Socket Material 316 Stainless Steel
- Basic Gauge Sensor Material Stainless Steel
- Gauge Sensor Material Stainless Steel
- Gauge Lens Material Safety Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 250 Degrees F
- Gauge Special Options Heavy Duty
- For Use With Media Compatible with 316L Stainless Steel
- Calibration Certificate Included No
- Series PPC
- Manufacturers Warranty Length 5 yr
- Features Pressure Relief Back, Solid Front
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: PPC5070SG45
- MPN: PPC5070-SG45
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 23151820
- UNSPSC Class ID: 18
- UNSPSC Commodity Name: Pharmaceutical industry machinery and equipment and supplies
- UNSPSC Commodity ID: 20
- UNSPSC Commodity Name: Pressure gauge
- UNSPSC Family ID: 15
- UNSPSC Family Name: Industrial process machinery and equipment and supplies
- UNSPSC Segment ID: 23
- UNSPSC Segment Name: Industrial Manufacturing and Processing Machinery and Accessories
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:46am UTC
Category: Pressure and Vacuum Measuring
