K4527 Pressure Gauge 4-1/2 Dial Size Black MPN:P3S6016-MAXI45
SKU
226-CXO-491A89
K4527 Pressure Gauge 4-1/2 Dial Size Black
K4527 Pressure Gauge 4-1/2 Dial Size Black is an essential tool for precise pressure measurement in various industries such as HVAC/R, laboratory research or automotive mechanics. With its large dial face ensuring easy readability and its durable construction delivering dependable performance under any condition, this precision instrument provides accurate measurements for unbeatable value.
Buy Winters item #P3S6016-MAXI45 from our huge selection of Measuring Tools & Sensors to show your support for our 🗽 Patriotic Veteran-Owned Business.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Metal
- Basic Gauge Wetted Parts Brass
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 600
- Gauge Secondary Range Units kPa
- Gauge Secondary Range Values 0 to 4140
- Gauge Accuracy +/-0.50%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled No
- Gauge Primary Range Smallest Graduation 50/100
- Gauge Case Material Steel
- Gauge Primary Range Numbered Graduations 100/500
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Brass
- Gauge Sensor Material Brass
- Gauge Lens Material Glass
- Basic Gauge Lens Material Glass
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Maximum Reading Pointer
- For Use With Air, Brass, Fresh Water, Industrial Applications, Media Compatible with Copper Alloy, Oil, Steam
- Calibration Certificate Included No
- Series P3S
- Manufacturers Warranty Length 5 yr
Manufacturer Details
- Manufacturer: Winters
- Condensed Mfg Number: P3S6016MAXI45
- MPN: P3S6016-MAXI45
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: CN
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on September 26, 2024 1:02pm UTC
Category: Pressure and Vacuum Measuring
