Speed Reducer Indirect Drive 10 1 MPN:E13XWNS 10:1
Speed Reducer Indirect Drive type 10 features an oil-bath lubrication method with an integrated cooler for longer gear life span under heavy duty use. The output torque rating of 26650 Nm makes it ideal for use in heavy industries and applications requiring high power transmission capabilities. It has a helical bevel gears arrangement allowing it to manage high radial loads as well. This speed reducer provides an easy way to connect motor shafts directly without any need for keyways, ensuring secure mounting for reliable operation. Applications that benefit from this type of indirect drive speed reducer include steel and plastics processing machines, conveyors, wind turbines or in various machine tools where massive amounts of torque needs to be managed safely at low rotational speeds.
Technical Specifications
- Item Speed Reducer
- Speed Reducer Type Indirect Drive
- Shaft Orientation Right Angle
- Duty Washdown
- Input RPM 1,725
- Nominal Output RPM 172
- Worm Center Distance 1.33 in
- Frame Solid Input Shaft
- Overhung Load 290 lb
- Nominal Ratio 10:1
- Max. Input HP 0.75 hp
- Max. Output Torque 248.0 in-lb
- Output Torque @ 1/4 HP 83 in-lb
- Output Torque @ 1/3 HP 109 in-lb
- Output Torque @ 1/2 HP 165 in-lb
- Output Torque @ 3/4 HP 248 in-lb
- Number of Stages 1
- Rotation Reversible
- Mounting Universal
- Lubrication Mobil Glygoyle(R) 460
- Gear Type Worm
- Housing Material Cast Iron
- Finish Epoxy Coating System
- Single/Double Output/Universal Double Output
- Solid/Hollow Output Shaft Solid
- Output Shaft Dia. 3/4 in
- Output Shaft Height 1 3/4 in
- Standards NSF/ASTM B-117
Manufacturer Details
- Manufacturer: Winsmith
- Condensed Mfg Number: E13XWNS101
- MPN: E13XWNS 10:1
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483905090
- GDS Category Name: Speed Reducers
- GDS Family Name: Speed Reducers
- GDS Segment Name: Power Transmission
- UNSPSC: 26111503
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Kinetic power transmission
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Adjustable speed drives
- UNSPSC Family ID: 11
- UNSPSC Family Name: Batteries and generators and kinetic power transmission
- UNSPSC Segment ID: 26
- UNSPSC Segment Name: Power Generation and Distribution Machinery and Accessories
Shipping Details
- Not For Sale In: HI AK PR
