Laydown Threading Insert: CNGA64IR5BUT75T2 VTX, Solid Carbide MPN:060-00001
Laydown Threading Insert: CNGA64IR5BUT75T2 VTX, Solid Carbide
Laydown Threading Insert: CNGA64IR5BUT75T2 VTX, Solid Carbide Uncoated, Right Hand Internal BUT Thread, 5 TPI, 3/4" Inscribed Circle, 6.35mm Thick
Product Information
- : 060-00001
- Coating Process: PVD
- Coating/Finish: Uncoated
- Included Angle: 3
- Inscribed Circle (Decimal Inch): 0.7500
- Inscribed Circle (Inch): 3/4
- Insert Hand: Right Hand
- Insert Material: Solid Carbide
- Insert Style: CNGA64IR
- Manufacturer Grade: VTX
- Manufacturers Catalog Number: False
- Material Grade: Micrograin
- Number of Teeth Per Side: 2
- Series: CNGA
- Thickness (Decimal Inch - 4 Decimals): 0.2500
- Thickness (Inch): 1/4
- Thickness (mm): 6.35
- Thread Standard: BUT
- Thread Type: Internal
- Threads Per Inch: 5
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: IL, Israel
- TAA Compliant: Yes
- UNSPSC: 23291804
- CA Restricted (Prop 65): Unknown
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 0.05
- Prohibited States: AK,HI,PR
Product info last updated on April 1, 2025 5:56pm UTC
Category: Threading and Thread Mill Inserts
