Split-Phase General Purpose Motor, 1/4 hp HP, 208-230V AC Voltage, 56 Frame, 1, 140 RPM Nameplate RPM MPN:7998
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4404314
Split-Phase General Purpose Motor, 1/4 hp HP, 208-230V AC Voltage, 56 Frame, 1, 140 RPM Nameplate RPM
This 1/4 hp split-phase general purpose motor is designed for a wide range of applications, including industrial and commercial use. Its 1,140 RPM nameplate speed and continuous duty cycle make it suitable for tasks that require consistent power output. The motor's open drip-proof enclosure and cradle base mounting type provide easy installation and maintenance. With a service factor of 1.35 and thermal protection, this motor can operate in temperatures up to 40°C, making it ideal for use in environments with high temperatures. Its compact size and low weight also make it suitable for use in space-constrained areas.
Top product features:
- Split-Phase motor design
- Continuous duty cycle
- Keyed motor shaft
Top product applications:
- Pumps and irrigation systems
- Conveyor systems and material handling equipment
- Industrial fans and blowers
General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/4 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 208-230V AC, Full Load Amps 2.9 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base, Motor Shaft Design Keyed
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.50
- Package Width: 10.50
- Package Height: 10.88
- Package Weight: 25.00
Product info last updated on February 7, 2026 4:59pm UTC
Category: Motors
