Split-Phase General Purpose Motor, 1/9 hp HP, 115V AC Voltage, 56Z Frame, 1, 725 RPM Nameplate RPM MPN:3053

General Purpose Motor, Single Phase, Motor Design Split-Phase, 1/9 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 2, Voltage 115V AC, Full Load Amps 7.1 A, 56Z Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base, Inverter Rated Not Applicable
