2 Bolt Flng Brg Radial 1 3/16in Bore MPN:YCJT 1 3/16 SGT
2 Bolt Flng Brg Radial 1 3/16in Bore
2 Bolt Flanging Bridge Anchor is an industrial grade fastening solution used to securely fix pipes or ducts, manufactured from premium quality steel with black oxide finish for increased strength and rust prevention. Measuring at 1.90 inch outside diameter, this flange offers a bolt-style design that requires two bolts providing a durable connection and enhanced support on various surfaces. The product can be used across industries like plumbing, HVAC, automotive and manufacturing to firmly anchor pipes or mount components with precision.
Buy Timken item #YCJT 1 3/16 SGT to have a positive impact 📈 on our community of Service Disabled Veteran-Owned Business partners.
Technical Specifications
- Item 2-Bolt Flange Bearing
- Mounted Bearing Item 2-Bolt Flange Bearing
- Bearing Insert Type Ball
- Bore Dia. 1 3/16 in
- Shaft Locking Type Set Screw
- Bearing Housing Material Type Cast Iron
- Bearing Insert Material 52100 Chrome Steel
- Bolt Hole Center-to-Center 4 19/32 in
- Series YCJT
- Bolt Size 7/16 in
- Overall Height 5 9/16 in
- Overall Width 1 21/32 in
- Overall Length 3 1/8 in
- Bearing Lubrication Mobil Polyrex EM or NLGI #2 Equivalent
- Dynamic Load Capacity 4,800 lb
- Static Load Capacity 2,500 lb
- Temp. Range -65 Degrees to 200 Degrees F
- Finish Powder Coated
- Dimension A 1 11/64 in
- Dimension B 1 35/64 in
- Dimension E 1 23/32 in
- Dimension F 1 37/64 in
- Dimension H 5 9/16 in
- Dimension J 4 19/32 in
- Dimension L 3 1/8 in
- Dimension N 29/64 in
Manufacturer Details
- Manufacturer: Timken
- Condensed Mfg Number: YCJT1316SGT
- MPN: YCJT 1 3/16 SGT
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Flange Mount Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171501
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Flanged bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:42am UTC
Category: Bearings
