Radial Ball Brg 6312 60mm Bore Alloy Stl MPN:312KDD
Radial Ball Brg 6312 60mm Bore Alloy Stl
The Timken radial ball bearing is an essential component for power transmission applications in various industries such as construction, agriculture, and automotive. With its single-row design, it delivers superior load capacity, low friction, and exceptional reliability. This bearing's double shielding offers increased protection against dirt, dust, and water, ensuring longer life and maximum performance in demanding conditions. The 60 mm bore diameter makes it suitable for various size ranges, making it a versatile choice for various applications, including gear drives, conveyor systems, and motor-reducer sets. Choose Timken radial ball bearings for superior quality, precision, and durability to enhance the performance of your machinery.
Top product features:
- Single-row alignment for exceptional load capacity and low friction
- Double shielding for increased protection against dirt, dust, and water
- 60 mm bore diameter for versatile size range applications
Top product applications:
- Heavy machinery and equipment where high load capacity and low friction are essential
- Agricultural and construction vehicles to enhance power transmission and durability
- Industrial transmissions for increased reliability and long service life
This radial ball bearing features single-row alignment.
Technical Specifications
- Item Radial Ball Bearing
- Unmounted Bearing Item Radial Ball Bearing
- Single Row/Double Row Single Row
- Seal/Shield Type Double Shielded
- Bore Dia. 60 mm
- Bore Tolerance +0/-.015mm
- Outside Dia. 130 mm
- Outside Dia. Tolerance +0/-.018mm
- Width 31 mm
- Shield Material Steel
- ABEC Tolerance 1
- Dynamic Load Capacity 20,800 lb
- Static Load Capacity 11,600 lb
- Max. RPM 2,632 RPM
- Temp. Range -60 Degrees to 200 Degrees F
- Bearing Material Steel
- Cage Material Steel
- Lubrication Chevron SRI 2
- Industry Number 312KDD
Manufacturer Details
- Manufacturer: Timken
- Condensed Mfg Number: 312KDD
- MPN: 312KDD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Radial and Deep Groove Ball Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
