Radial Ball Brg 6209 45mm Bore Alloy Stl MPN:209WDDN
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxo-44z855
Radial Ball Brg 6209 45mm Bore Alloy Stl
The Timken Radial Ball Bearing is an essential component for enhancing power transmission in various industrial applications. With a bore diameter of 45 mm and double shielded seal/shield type, this radial ball bearing delivers maximum durability and long-lasting performance. Its single row alignment design ensures efficient functioning, while the alloy steel construction adds to its sturdiness. Whether it's used in machinery, robotics, conveyors, or transmission systems, this unmounted radial ball bearing offers exceptional stability and high-speed capacity for smoother operation and reduced maintenance costs. Invest in Timken's Radial Ball Bearing and witness the difference it makes in your power transmission system!
Top product features:
- Alloy steel construction for enhanced durability and sturdiness
- Double shielded seal/shield type for maximum protection and long-lasting performance
- Single row alignment for efficient functioning and high-speed capacity
Top product applications:
- Industrial machinery: The Timken Radial Ball Bearing can be used in various industrial machines, such as mills, conveyors, gearboxes, or pumps to ensure smooth operation and reduced maintenance costs.
- Robotics: In robotic applications, the double shielded seal/shield type of this bearing can protect against dust, dirt, and water damage, enhancing its durability in high-usage situations.
- Transmission systems: The single row alignment feature of Timken's radial ball bearing can improve the efficiency of transmission systems by providing a stable performance even at high speeds.
This radial ball bearing features single-row alignment.
Technical Specifications
- Item Radial Ball Bearing
- Unmounted Bearing Item Radial Ball Bearing
- Single Row/Double Row Single Row
- Seal/Shield Type Double Shielded
- Bore Dia. 45 mm
- Bore Tolerance +0/-.012mm
- Outside Dia. 85 mm
- Outside Dia. Tolerance +0/-.015mm
- Width 19 mm
- Shield Material Steel
- Retainer Type Snap Ring
- ABEC Tolerance 1
- Dynamic Load Capacity 11,200 lb
- Static Load Capacity 7,100 lb
- Max. RPM 3,846 RPM
- Temp. Range -60 Degrees to 200 Degrees F
- Bearing Material Steel
- Cage Material Steel
- Lubrication Chevron SRI 2
- Industry Number 209WDDN
Manufacturer Details
- Manufacturer: Timken
- Condensed Mfg Number: 209WDDN
- MPN: 209WDDN
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Radial and Deep Groove Ball Bearings
- GDS Family Name: Bearings
- GDS Segment Name: Power Transmission
- UNSPSC: 31171504
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 04
- UNSPSC Commodity Name: Ball bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B00JTHFW8U
Product info last updated on October 13, 2023 5:39pm UTC Category: Bearings
