K4573 Pressure Gauge 0 to 600 psi 4-1/2 Dial MPN:FA-LFP-410-CG-WOB
SKU
226-CXG-52VR71
K4573 Pressure Gauge 0 to 600 psi 4-1/2 Dial
K4573 pressure gauge measures accurately and reliably in air and liquid pressures ranging from 0 to 600 psi, with a dial display measuring at four digits and a full sweep design for ease of reading; this model has an overall size of 4-1/2 inches, ensuring that it is easily accessible when taking measurements. Its stainless steel material makes the gauge highly durable and long-lasting while standing up to rugged conditions, corrosion-prone environments, or harsh treatment; additionally, this instrument offers precise accuracy with an outstanding two percent full scale accuracy for exceptional precision and reliability in readings.
This gauge features plastic case construction to resist corrosion and impact in demanding applications.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 4 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 600
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable Yes
- Gauge Mounting Method U Clamp
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 20
- Gauge Case Material Nylon
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Copper Alloy
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Copper Alloy
- Gauge Lens Material Plastic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Characteristics Reverse Dial, White On Black
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series FA
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Thuemling
- Condensed Mfg Number: FALFP410CGWOB
- MPN: FA-LFP-410-CG-WOB
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026204000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 23151820
- UNSPSC Class ID: 18
- UNSPSC Commodity Name: Pharmaceutical industry machinery and equipment and supplies
- UNSPSC Commodity ID: 20
- UNSPSC Commodity Name: Pressure gauge
- UNSPSC Family ID: 15
- UNSPSC Family Name: Industrial process machinery and equipment and supplies
- UNSPSC Segment ID: 23
- UNSPSC Segment Name: Industrial Manufacturing and Processing Machinery and Accessories
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on September 26, 2024 1:02pm UTC
Category: Pressure and Vacuum Measuring
