Pillow Block 1.000 In Bore 5.330 In L MPN:FNYBUTFB16LS
Titan USA's Pillow Block 1.000 in bore 5.330 in L offers a rugged construction to support heavy loads and resist vibration for smooth operation in harsh environments, making it ideal for use in mining, agriculture or construction equipment as well as conveyors and material handling systems. It is made from high-quality cast iron with ductile iron housings providing excellent load-carrying capacity, while its one-piece design eliminates alignment problems and wear outs associated with traditional designs. The Titan Pillow Block comes with a set screw locking mechanism for easy mounting ensuring that your equipment runs efficiently without maintenance interruptions. Its affordable cost makes this an attractive solution for professional mechanics, technicians and machine builders looking for reliable power tools and accessories at competitive prices in the Power Tools and Accessories market segment.
Technical Specifications
- Item Linear Pillow Block Bearing
- Type Closed, Twin Flange
- Bore Dia. (In.) 1 in
- Overall Width (In.) 2.75 in
- Overall Length (In.) 5.33 in
- Overall Height (In.) 2.75 in
- Body Width (In.) 2.75 in
- Flange Dia. (In.) 2.750 x 2.750
- Flange Thickness (In.) 0.5 in
- Barrel Dia. (In.) 2.25 in
- Mounting Hole Center (In.) 2.125 in
- Mounting Hole Dia. (In.) 0.28 in
- Self-Alignment All Direction
- Static Load Capacity (Lb.) 7,000
- Max. Pv 10,000 lb/sq in-fpm
- Steady State Speed - Continuous Dry 140 fpm
- Steady State Speed - Intermittent Dry 400 fpm
- Temp. Range (F) -400 - 550
- Locking Type Setscrew
- Bearing Type FlouroNyliner
- Liner TEP 950
- Lubrication No Lubrication System
- Material Aluminum
- Color Silver
- For Use With Thomson Shafting
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: FNYBUTFB16LS
- MPN: FNYBUTFB16LS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Mounted Linear Bearings
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
