Pillow Block 0.500 In Bore 1.690 In L MPN:FNYBUFB08LLS
The perfect combination of strength and versatility makes our heavy duty pillow block bearing housing ideal for demanding applications requiring robust axial guidance, rotational positioning, as well as high load capacity. Manufactured from top-grade materials - inner/outer rings are made with cold rolled 1035 steel while outer housings utilize G25 cast iron providing optimal strength and stability. Key benefits include wide inner ring ribs resistant to cantilever loads distributing radial forces evenly across double lip seals enhancing longevity compared to conventional single lip models. Ensure precision motion in your machines with easy installation on four mounting bolts with interference fit outer housing components. Use this premium quality bearing housing in industries such as construction machinery, automotive and agricultural equipment for smooth operations!
Technical Specifications
- Item Linear Pillow Block Bearing
- Type Closed, Flanged
- Bore Dia. (In.) 0.5 in
- Overall Width (In.) 1.63 in
- Overall Length (In.) 1.69 in
- Overall Height (In.) 1.63 in
- Body Width (In.) 1.63 in
- Flange Dia. (In.) 1.630 x 1.630
- Flange Thickness (In.) 0.25 in
- Barrel Dia. (In.) 1.25 in
- Mounting Hole Center (In.) 1.25 in
- Mounting Hole Dia. (In.) 0.19 in
- Self-Alignment All Direction
- Static Load Capacity (Lb.) 970
- Max. Pv 10,000 lb/sq in-fpm
- Steady State Speed - Continuous Dry 140 fpm
- Steady State Speed - Intermittent Dry 400 fpm
- Temp. Range (F) -400 - 550
- Locking Type Setscrew
- Bearing Type FlouroNyliner
- Liner TEP 950
- Lubrication No Lubrication System
- Material Aluminum
- Color Silver
- For Use With Thomson Shafting
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: FNYBUFB08LLS
- MPN: FNYBUFB08LLS
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- GDS Category Name: Mounted Linear Bearings
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
