Ball Bushing Die Bore Dia 1.250 In MPN:DS20
The Tap Set: 5/16-24 UNF, 4 Flute, Bottoming Plug & Taper, High Speed Steel, Bright Finish is an essential tool for drilling precise threads into various materials in production settings or workshops. Featuring a bottoming plug with taper tip allowing users to start threading at any point while eliminating burrs, the tap set delivers clean cuts and consistent threads without risk of stripping even in hard surfaces such as stainless steel. The 4 flutes configuration provides smooth chip removal during operation while its high-speed steel construction ensures robustness, wear-resistance, and long-lasting performance suitable for repetitive use. Easy to handle with a black oxide finish that minimizes slippage and corrosion over time - this tap set is the go-to solution for precise thread creation on any given application from automotive assembly lines, machining shops to small-scale workshop operations where threading accuracy counts most.
Technical Specifications
- Item Ball Bushing Die Set
- Bore Dia. (In.) 1.25 in
- Bore Tolerance +/-0.001
- Outside Dia. (In.) 2.31 in
- Pilot Dia. (In.) 1.751/1.570
- Pilot Length (In.) 1.19 in
- Clamp Dia. (In.) 3.22 in
- Overall Length (In.) 4.86 in
- Bolt Circle Dia. (In.) 2.54 in
- Dynamic Load Capacity (Lb.) 520
- Temp. Range (F) 0 - 600
- Bearing Type Die Set
- Material Steel
- Finish Steel
- Color Steel
- For Use With Thomson Shafting
- Includes Clamps and Mounting Screws
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: DS20
- MPN: DS20
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308040
- GDS Category Name: Linear Die Sets
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
