Ball Bushing Die Bore Dia 1.000 In MPN:DS16
The Cutoff & Grooving Support Blade for Indexables is a versatile accessory specifically designed to support indexable insert cutting tools when working with metals. With its left-handed design, it is ideal for machining internal grooves and threads or performing secondary cut-off operations on various materials such as aluminum, cast iron, carbon steel, stainless steel and titanium alloys. Manufactured from high-grade steel with a precision ground cutting edge and an overall length of 1 inch, it ensures a clean, sharp cut without chatter or wobbling during use. It also features a standard ISO 4712-compliant P60 tooling hole that makes mounting simple onto the desired indexable insert holder or boring head. The blade's compatibility with Helical or Modular Grip insert systems means users have access to numerous options when choosing inserts depending on their application needs, material requirements and desired edge geometry at a competitive price point.
Technical Specifications
- Item Ball Bushing Die Set
- Bore Dia. (In.) 1.0 in
- Bore Tolerance +/-.001
- Outside Dia. (In.) 1.91 in
- Pilot Dia. (In.) 1.501/1.501
- Pilot Length (In.) 0.94 in
- Clamp Dia. (In.) 2.82 in
- Overall Length (In.) 4.11 in
- Bolt Circle Dia. (In.) 2.12 in
- Dynamic Load Capacity (Lb.) 350
- Temp. Range (F) 0 - 600
- Bearing Type Die Set
- Material Steel
- Finish Steel
- Color Steel
- For Use With Thomson Shafting
- Includes Clamps and Mounting Screws
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: DS16
- MPN: DS16
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8483308040
- GDS Category Name: Linear Die Sets
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
