Ball Bushing Bore Dia 1.250 In MPN:SSU20OPN
Ball Bushing Bore Dia 1.250 In
The Spiral Flute Tap #12-24 UNC, featuring a semi-bottoming design with three flutes in high-speed steel (HSS) and zirconium nitride (ZrN) finish delivers unparalleled performance for users across industries looking to cut through various materials efficiently. This tap is suitable for applications that require higher precision such as aerospace, automotive manufacturing, or machining shops working with aluminum and steel materials. The cutting-edge coating provides longer lifespan and reduced wear on the tap's surface enabling smoother, faster cuts and effortless ejection of chips for consistent threading outcomes while lower friction allows it to function effectively even at higher RPM's without overheating.
Super Smart Ball Bushing®Designed to maintain diametrical fit when installed in housings that are slightly out-of-round. Provide twice the load-carrying capacity, or 8 times the travel life of Super Ball Bushing® bearings?and 6 times the load, or 216 times the travel life of conventional linear bearings.Linear Ball Bushing Bearings• Steady-state speeds to 10 fps; acceleration to 450 fps2 Max. temp.: 185° F Coefficient of friction as low as 0.001 Self-aligning
Technical Specifications
- Item Ball Bushing Bearing
- Type Open
- Bore Dia. 1.25 in
- Inside Dia. Tolerance +/-0.001
- Outside Dia. 2 in
- Slot Width (In.) 0.62 in
- Slot Angle (Degrees) 30
- Retention Hole Dia. (mm) 0.2 in
- Retention Hole Location 0.19 in
- Between Grooves (mm) 2.031 in
- Length (In.) 2.625 in
- Accelerated Speed 450 fps
- Steady State Speed 10 fps
- Temp. Range (F) 0 a 185
- Self-Alignment Yes
- Material Delrin
- Required Housing Bore Dia. (In.) 2 in
- For Use With Thomson Shafting
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: SSU20OPN
- MPN: SSU20OPN
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8482105012
- GDS Category Name: Unmounted Linear Ball Bearings
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 9:52pm UTC
Category: Linear Motion
