Super Ball Bushing Bore Dia 1.000 In MPN:SUPER16OPN
Super Ball Bushing Bore Dia 1.000 In
Screw Cup Point - 3/4-10 is a self-tapping screw designed for steel and other high tensile strength materials. This ScktStScrw fastener has a cup point which allows easy starting into wood or light sheet metal, while providing excellent holding power in solid materials. With a length of 5/8, it's ideal for use in automotive repair shops, construction sites and general fabrication work. The PK450 packaging includes four hundred pieces, making this screw cup point an essential product for professionals and DIY enthusiasts alike who require dependable fastening solutions for various applications.
Super Ball Bushing®Wear-resistant, engineered polymer retainers and outer sleeves reduce inertia and noise in critical high-speed applications. Offer 3 times the load capacity, or 27 times the travel life of conventional linear bearings.Linear Ball Bushing Bearings• Steady-state speeds to 10 fps; acceleration to 450 fps2 Max. temp.: 185° F Coefficient of friction as low as 0.001 Self-aligning
Technical Specifications
- Item Super Ball Bushing Bearing
- Type Open
- Bore Dia. 1.0 in
- Inside Dia. Tolerance +/-.001
- Outside Dia. 1.563 in
- Slot Width (In.) 0.56 in
- Slot Angle (Degrees) 15
- Retention Hole Dia. (mm) 0.14 in
- Retention Hole Location 0.13 in
- Between Grooves (mm) 1.884 in
- Length (In.) 2.25 in
- Accelerated Speed 450 fps
- Steady State Speed 10 fps
- Temp. Range (F) 0 - 185
- Self-Alignment Yes
- Material Delrin
- Required Housing Bore Dia. (In.) 1.563 in
- For Use With Thomson Shafting
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: SUPER16OPN
- MPN: SUPER16OPN
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8482105012
- GDS Category Name: Unmounted Linear Ball Bearings
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 9:52pm UTC
Category: Linear Motion
