Super Ball Bushing Bore Dia 0.375 In MPN:SUPER6
Super Ball Bushing Bore Dia 0.375 In
The shrink wrap roll is perfect for bundling or repairing packages while offering extra-wide coverage to secure a vast array of materials with 14in width and an extended 4375' length; its LLDPE material is eco-friendly and provides strong resistance to abrasion, punctures and moisture, ensuring durability in diverse outdoor or indoor settings while reducing packaging waste. The reinforced edges increase tear resistance to help safeguard valuable contents making it suitable for industries like retail stores or warehouses that require bulk or delicate item securing during transportation with cost-effectiveness when compared to prefabricated sizes.
Super Ball Bushing®Wear-resistant, engineered polymer retainers and outer sleeves reduce inertia and noise in critical high-speed applications. Offer 3 times the load capacity, or 27 times the travel life of conventional linear bearings.Linear Ball Bushing Bearings• Steady-state speeds to 10 fps; acceleration to 450 fps2 Max. temp.: 185° F Coefficient of friction as low as 0.001 Self-aligning
Technical Specifications
- Item Super Ball Bushing Bearing
- Type Closed
- Bore Dia. 0.375 in
- Inside Dia. Tolerance +/-.001
- Outside Dia. 0.625 in
- Between Grooves (mm) 0.699 in
- Length (In.) 0.875 in
- Accelerated Speed 450 fps
- Steady State Speed 10 fps
- Temp. Range (F) 0 - 185
- Self-Alignment Yes
- Material Delrin
- Required Housing Bore Dia. (In.) 0.625 in
- For Use With Thomson Shafting
Manufacturer Details
- Manufacturer: Thompson
- Condensed Mfg Number: SUPER6
- MPN: SUPER6
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 3917400000
- GDS Category Name: Unmounted Linear Ball Bearings
- GDS Family Name: Linear Motion
- GDS Segment Name: Power Transmission
- UNSPSC: 31171506
- UNSPSC Class ID: 15
- UNSPSC Commodity Name: Bearings
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Linear bearings
- UNSPSC Family ID: 17
- UNSPSC Family Name: Bearings and bushings and wheels and gears
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on April 3, 2024 9:52pm UTC
Category: Linear Motion
