Laydown Threading Insert: TME200R T130A, Cermet MPN:1C70115
Laydown Threading Insert: TME200R T130A, Cermet
Laydown Threading Insert: TME200R T130A, Cermet Uncoated, Right Hand External ISO Thread, 3/8" Inscribed Circle, 0.143" Thick
Product Information
- : 1C70115
- Coating/Finish: Uncoated
- Corner Radius (Decimal Inch): 0.0106
- Hole Diameter (Decimal Inch): 0.1500
- Included Angle: 60
- Inscribed Circle (Decimal Inch): 0.3750
- Inscribed Circle (Inch): 3/8
- Insert Hand: Right Hand
- Insert Material: Cermet
- Insert Size Code: 200
- Insert Style: TME
- Manufacturer Grade: T130A
- Pitch (mm): 2.00
- Primary Workpiece Material: Stainless Steel; Steel
- Primary Workpiece Material Code: M; P
- Thickness (Decimal Inch - 4 Decimals): 0.1430
- Thread Standard: ISO
- Thread Type: External
Additional Information
- Hazardous Materials: No, oK to Ship Via Air
- Material Safety Data Sheet (MSDS) Required: No
- Country of Origin: JP, Japan
- TAA Compliant: Yes
- UNSPSC: 23291804
- CA Restricted (Prop 65): Unknown
- Package Length: 3.50
- Package Width: 1.50
- Package Height: 0.44
- Package Weight: 0.01
- Prohibited States: AK,HI,PR
Product info last updated on July 16, 2024 12:02pm UTC
Category: Threading and Thread Mill Inserts
