IEC Magnetic Contactor, 1NC/1NO, 208V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1D150LE7

• The SQUARE D - IEC Magnetic Contactor is a non-reversing, three-pole contactor designed for motor control and resistive load applications. It operates with a coil voltage of 208V AC and features an auxiliary contact configuration of 1NO/1NC. The device has a built-in bidirectional peak limiting diode suppressor that operates within specified parameters. With an average impedance of 0.6 mOhm at Ith 200 A 50 Hz for the power circuit, it performs as per specifications under stated conditions.

  Key Features:

• - Non-Reversing action suitable for motor control and resistive load applications.
• - Auxiliary Contacts Type: Mechanically linked 1 NO + 1 NC IEC 60947-5-1
• Mirror contact 1 NC IEC 60947-4-1
• - Coil Technology: Built-in bidirectional peak limiting diode suppressor to manage voltage spikes.
• - Connections - Terminals: Screw clamp terminals compatible with varying cable stiffness types and sizes.
• - Electrical Durability: Rated for up to one million cycles at less than or equal to440 V (AC).
• -Includes Protective Cover: Includes protective cover for use during operation.
• -Mounting Style: Can be mounted on DIN Rail or Plate
• -Rated Insulation Voltage: Power circuit rated at600 V CSA/UL
• Signalling circuit rated at690 V IEC
• -Rated Operational Current/Voltage : Up to200 A (at Less than140°F) at Less than or Equal to440 V AC AC- Rated Short-Time Withstand Current : Ranges from250 A (at40°Cfor10 min Power Circuit)to1400 A(at40°Cfor1 s Power Circuit)
