Circuit Breaker 100A 3P 600VAC JG MPN:JGL37100D81
SKU
226-CXG-6NHF4
Circuit Breaker 100A 3P 600VAC JG
Introducing the Square D 100A 3P 600VAC JG Circuit Breaker - designed for powerful protection in commercial and industrial environments. With a rating of up to 250A and an AC voltage rating of 600V, this circuit breaker is perfect for use in construction, oil and gas, marine, and other heavy-duty applications. The molded case enclosure houses current-carrying parts, mechanisms, and trip devices that ensure maximum reliability and protection against electrical damage. Its 3P configuration offers flexible wiring options, making it ideal for a wide range of applications. Choose the Square D 100A 3P 600VAC JG Circuit Breaker for peace of mind and unparalleled performance in your next project.
Top product features:
- Rating of up to 250A for powerful protection
- AC voltage rating of 600V for heavy-duty applications
- Flexible wiring options with 3P configuration
Top product applications:
- Construction sites for heavy electrical loads and equipment protection
- Marine vessels for shipboard power distribution and electrical protection
- Oil and gas industries for drilling rigs and pipeline control systems
J-frame Square D molded case circuit breakers are rated up to 250A and 600VAC and interrupt excessive current flows to protect devices from electrical damage. They're used in construction, oil and gas, marine, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 100 A
- AC Voltage Rating 600V AC
- Max. AIR Rating Not Rated
- For Use With Free Standing
- Series JG
- High Amp Trip Setting 600 A
- Low Amp Trip Setting 400 A
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating 500V DC
- Terminal Connection Box Lug
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Adjustable
- Phase Connection ABC
- Frame Size 250A/J
- Circuit Breaker Mounting Style Lug In/Lug Out
- Height 7.5 in
- Width 4.1 in
- Depth 5.0 in
- Min. Wire Size 4 AWG
- Max. Wire Size 3/0 AWG
- Circuit Breaker Actuator Toggle
- Standards BS, CCC, CE Marked, CEI, CSA Certified, Federal Specification W-C-375B/GEN, HACR, HID, IEC, NEMA, NMX, NOM, SWD, UL Listed, UNE, UTE, VDE
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: JGL37100D81
- MPN: JGL37100D81
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B002YF5FV8, B07M59DSMH, B00AT090O8
