Circuit Breaker 400A 2P 600VAC MJ MPN:MJL26400
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-6NHD0
Circuit Breaker 400A 2P 600VAC MJ
Introducing the Square D Molded Case Circuit Breaker, perfect for protecting your electrical devices from damage in industrial and commercial settings. With an impressive 400-amp rating and 600V AC voltage capacity, this breaker ensures reliable protection against excessive current flows. Designed for use with equipment gear, the Square D circuit breaker is ideal for construction sites, oil and gas facilities, and commercial buildings where durable and dependable circuit protection is essential. Save time and money by preventing electrical damage to your equipment with the Square D Molded Case Circuit Breaker.
Top product features:
- Amperage rating of 400 A for powerful current protection
- Rating of 600V AC for use in high voltage applications
- Molded case design for durable and long-lasting use
Top product applications:
- Industrial settings for overload and short circuit protection
- Commercial buildings for load management and fault interruption
- Outdoor environments where exposure to harsh weather conditions is a concern
M-frame Square D molded case circuit breakers are rated up to 800A and 600VAC and interrupt excessive current flows to protect devices from electrical damage. They're used in construction, commercial buildings, oil and gas, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 400 A
- AC Voltage Rating 600V AC
- Max. AIR Rating 25kA at 600V AC
- For Use With Equipment Gear
- Series MJ
- High Amp Trip Setting 4,000 A
- Low Amp Trip Setting 800 A
- Circuit Breaker Type Standard
- Number of Poles 2
- DC Voltage Rating Not Rated
- Terminal Connection Box Lug
- Trip Type Electronic
- Phase 1
- Instantaneous Trip Adjustable
- Phase Connection ABC
- Frame Size 800A/M
- Circuit Breaker Mounting Style Lug In/Lug Out
- Height 12.9 in
- Width 8.3 in
- Depth 8.1 in
- Min. Wire Size 3/0 AWG
- Max. Wire Size 500 MCM
- Circuit Breaker Actuator Toggle
- Standards BS, CCC, CEI, CSA Certified, Federal Specification W-C-375B/GEN, IEC, NEMA, NMX, UL Listed, UNE, UTE, VDE
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: MJL26400
- MPN: MJL26400
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
