Circuit Breaker 400A 3P 600VAC LAL MPN:LAL3640036M

Square D motor circuit protectors are rated up to 75A and 347VAC and interrupt excessive current flows to protect motor control centers from short circuits. They can be used with NEMA and IEC motor starters, overload relays, and contactors to offer more circuit protection. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.

Technical Specifications

• Item Molded Case Circuit Breaker
• Amps 400 A
• AC Voltage Rating 600V AC
• Max. AIR Rating 42kA at 240V AC
• For Use With NEMA Motor Starters
• Series LAL
• High Amp Trip Setting 4,000 A
• Low Amp Trip Setting 2,000 A
• Circuit Breaker Type Motor Circuit Protector
• Number of Poles 3
• DC Voltage Rating 250V DC
• Terminal Connection Lug
• Trip Type Thermal Magnetic
• Phase 3
• Instantaneous Trip Adjustable
• Phase Connection ABC
• Frame Size 400A/LA
• Circuit Breaker Mounting Style Free Standing
• Height 11.0 in
• Width 6.0 in
• Depth 5.84 in
• Min. Wire Size 1/0 AWG
• Max. Wire Size 250 MCM, 600 MCM
• Circuit Breaker Actuator Toggle
• Standards CSA, IEC, UL Listed

Manufacturer Details

• Manufacturer: Square D
• Condensed Mfg Number: LAL3640036M
• MPN: LAL3640036M

Label Details

• Hazardous Material: N
• Green Material Flag: N
• Country of Origin: MX
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536200020
• GDS Category Name: Molded Case Circuit Breakers
• GDS Family Name: Distribution
• GDS Segment Name: Electrical
• UNSPSC: 39121602
• UNSPSC Class ID: 16
• UNSPSC Commodity Name: Circuit protection devices and accessories
• UNSPSC Commodity ID: 02
• UNSPSC Commodity Name: Magnetic circuit breakers
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
