Circuit Breaker 150A Plug In 120/240V 2P MPN:HOM2150
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-5B682
Circuit Breaker 150A Plug In 120/240V 2P
Introducing the HOM series miniature circuit breakers from Square D - the perfect solution for upgrading your home or small business electrical systems! These reliable and convenient breakers plug directly into your load center, eliminating the need for cumbersome mounting hardware. With a 150A rating and AC voltage rating of 120/240V, they can handle even the toughest power demands. Plus, their low-level fault protection helps prevent damaging electrical issues down the line. The two-pole design offers versatility for a variety of applications. Upgrade your electrical system with ease - choose the HOM series miniature circuit breakers from Square D today!
Top product features:
- Plugs directly into Homeline load centers without DIN rail or bolts reduces installation time and effort
- Low-level fault protection helps prevent electrical issues and potential damage to the circuit breaker or equipment
- Two pole design offers versatility for a variety of applications
Top product applications:
- Homes used to protect electrical circuits in residential properties
- Small businesses used in breaker boxes to control power distribution in small commercial spaces
- RVs installed as part of an electrical panel system for circuit protection while on the road
These HOM series miniature circuit breakers plug into place in Homeline load centers without requiring DIN rail or bolts, so they're easier to install than unit-mount or bolt-on breakers. They interrupt currents when low-level faults are detected in the circuit. They connect to the power supply through bus bars, which eliminates the need to pigtail wires and helps organize the load center.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 150 A
- AC Voltage Rating 120/240V AC
- Circuit Breaker Type Standard
- Number of Poles 2
- DC Voltage Rating Not Rated
- Circuit Breaker Actuator Paddle
- Circuit Breaker Mounting Style Plug In
- Compatible Panelboard/Load Center Series HOM
- Phase Single
- Series HOM
- Max. AIR Rating 10kA at 120/240V AC
- For Use With Homeline Load Center
- Terminal Connection Lug
- Frame Size 100A/HOM
- Length 3.13 in
- Width 2 in
- Depth 2.98 in
- Min. Operating Temp. 104 Degrees F
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 4 AWG
- Max. Wire Size 300 MCM
- Standards CSA Certified, HACR, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: HOM2150
- MPN: HOM2150
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
