Circuit Breaker 30A 3P 690VAC BJA MPN:BJA36030
Circuit Breaker 30A 3P 690VAC BJA
Introducing Square D's B-frame molded case circuit breaker, rated up to 30A and perfect for industrial control panels, commercial OEMs, and electrical distribution equipment. Designed for maximum protection, it interrupts excessive current flows to guard against electrical damage. The product comes in a compact size but don't let that fool you - its current-carrying parts, mechanisms, and trip devices are robust enough to handle demanding applications. This circuit breaker features an AC voltage rating of 690V and a maximum AIR rating of 100kA at 120/240V AC. The molded case construction ensures durability in harsh environments, making it suitable for various industries. Boost your electrical system's safety with Square D's Circuit Breaker 30A 3P 690VAC BJA today!
Top product features:
- AC Voltage Rating: The Circuit Breaker comes with an impressive AC voltage rating of 690V, suitable for demanding applications in various industries.
- Maximum AIR Rating: With a maximum AIR rating of 100kA at 120/240V AC, this product offers superior protection against electrical damage and faults.
- Molded Case Construction: The molded case design provides robust durability that stands up to harsh environments and ensures long-lasting performance in industrial and commercial applications.
Top product applications:
- Industrial Control Panels: The Circuit Breaker can be used in industrial control panels to provide maximum protection against electrical damage and faults in demanding environments.
- Commercial OEM: This product is suitable for use in commercial original equipment manufacturing, where high-performance circuit breakers are needed to meet the demands of various applications.
- Electrical Distribution Equipment: The Circuit Breaker can be used as part of electrical distribution equipment to ensure optimal safety and performance in electrical systems.
B-frame Square D molded case circuit breakers are rated up to 125A and interrupt excessive current flows to protect devices from electrical damage. They're used in industrial control panels, commercial OEM, electrical distribution equipment, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 30 A
- AC Voltage Rating 690V AC
- Max. AIR Rating 100kA at 120/240V AC
- For Use With Electrical Distribution Equipment, Industrial Control Panels
- Series BJA
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Al Mechanical Lug OFF End, I-Line ON End
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 125A/BJ
- Circuit Breaker Mounting Style I-Line
- Height 5.39 in
- Width 3.19 in
- Depth 3.5 in
- Min. Wire Size 14 AWG
- Max. Wire Size 2 AWG
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 158 Degrees F
- Min. Operating Temp. -13 Degrees F
- Standards CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: BJA36030
- MPN: BJA36030
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536509045
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121616
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 16
- UNSPSC Commodity Name: Molded case circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on January 19, 2024 5:04pm UTC
Category: Distribution
