Circuit Breaker 70A 3P 525VAC BGA MPN:BGA36070
Introducing Square D's molded case circuit breaker - the perfect electrical protection solution for your industrial or commercial needs! Rated up to 125A, these breakers are designed to handle excessive current flows and prevent electrical damage to your devices. With an AC voltage rating of 525VAC and a max. interrupting rating of 100kA at 240VAC, you can trust these breakers to perform under the toughest conditions. Their molded case construction ensures durability and ease of installation, making them a must-have for electrical distribution equipment and industrial control panels. Plus, their current carrying parts, mechanisms, and trip devices are all contained within the case for easy maintenance and troubleshooting. Invest in Square D's molded case circuit breaker today and enjoy the peace of mind that comes with top-notch electrical protection!
Top product features:
- 125A rating for handling excessive current flows
- AC voltage rating of 525VAC for tough conditions
- Molded case construction for durability and ease of installation
Top product applications:
- Industrial control panels
- Commercial OEM
- Electrical distribution equipment
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 70 A
- AC Voltage Rating 525V AC
- Max. AIR Rating 100kA at 240V AC
- For Use With Electrical Distribution Equipment, Industrial Control Panels
- Series BGA
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Al Mechanical Lug OFF End, I-Line ON End
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 125A/BG
- Circuit Breaker Mounting Style I-Line
- Height 5.39 in
- Width 3.19 in
- Depth 3.5 in
- Min. Wire Size 14 AWG
- Max. Wire Size 2 AWG
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 158 Degrees F
- Min. Operating Temp. -13 Degrees F
- Standards CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: BGA36070
- MPN: BGA36070
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121616
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 16
- UNSPSC Commodity Name: Molded case circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
