Circuit Breaker 50A 3P 525VAC BGA MPN:BGA36050
Circuit Breaker 50A 3P 525VAC BGA
The Square D Molded Case Circuit Breaker is an essential piece of equipment for ensuring the safety and protection of electrical devices in industrial and commercial environments. With its ability to interrupt excessive current flows, this circuit breaker provides superior protection against electrical damage and short circuits. Its molded case construction ensures durability and resistance to heat dissipation during operation, while its 50A rating allows for optimal current control. Ideal for use in industrial control panels, commercial OEM, electrical distribution equipment, and other industrial or commercial applications, the Square D Molded Case Circuit Breaker is a reliable and cost-effective solution for your electrical needs.
Top product features:
- Interrupt excessive current flows to protect devices from electrical damage
- Durable molded case construction
- Optimal 50A rating for current control
Top product applications:
- Industrial control panels
- Commercial OEM applications
- Electrical distribution equipment
B-frame Square D molded case circuit breakers are rated up to 125A and interrupt excessive current flows to protect devices from electrical damage. They're used in industrial control panels, commercial OEM, electrical distribution equipment, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 50 A
- AC Voltage Rating 525V AC
- Max. AIR Rating 100kA at 240V AC
- For Use With Electrical Distribution Equipment, Industrial Control Panels
- Series BGA
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Al Mechanical Lug OFF End, I-Line ON End
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 125A/BG
- Circuit Breaker Mounting Style I-Line
- Height 5.39 in
- Width 3.19 in
- Depth 3.5 in
- Min. Wire Size 14 AWG
- Max. Wire Size 2 AWG
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 158 Degrees F
- Min. Operating Temp. -13 Degrees F
- Standards CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: BGA36050
- MPN: BGA36050
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121616
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 16
- UNSPSC Commodity Name: Molded case circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
