Circuit Breaker 60A 2P 525VAC BGA MPN:BGA260601
Introducing Square D's Molded Case Circuit Breakers - the perfect solution for electrical protection in any industrial or commercial setting. With ratings up to 125A and able to interrupt excessive current flows of 60kA at 240V AC, these breakers are designed to protect your devices from potential damage caused by electrical issues. Their molded case enclosure contains all necessary components for safe and efficient operation, making them ideal for use in control panels, OEM equipment, and electrical distribution systems. With their durable construction and versatile applications, Square D's Molded Case Circuit Breakers provide reliable protection and peace of mind for any electrical system. Invest in safety and security today with Square D's industry-leading circuit breakers.
Top product features:
- Rating up to 125A Offers increased capacity and versatility for various electrical needs.
- Ability to interrupt excessive current flows of 60kA at 240V AC Ensures maximum protection against electrical damage and potential hazards.
- Molded case enclosure Provides a durable and compact design suitable for various industrial and commercial applications.
Top product applications:
- Industrial control panels Suitable for use in controlling and monitoring electrical systems in factories or other industrial settings.
- Commercial OEM equipment Can be used as part of larger electrical systems or machinery designed for commercial settings.
- Electrical distribution equipment Ideal for protecting and managing electrical circuits in various distribution setups such as power stations, substations, or generators.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 60 A
- AC Voltage Rating 525V AC
- Max. AIR Rating 100kA at 240V AC
- For Use With Electrical Distribution Equipment, Industrial Control Panels
- Series BGA
- Circuit Breaker Type Standard
- Number of Poles 2
- DC Voltage Rating Not Rated
- Terminal Connection Al Mechanical Lug OFF End, I-Line ON End
- Trip Type Thermal Magnetic
- Phase 1
- Instantaneous Trip Fixed
- Phase Connection AB
- Frame Size 125A/BG
- Circuit Breaker Mounting Style I-Line
- Height 5.39 in
- Width 2.13 in
- Depth 3.5 in
- Min. Wire Size 14 AWG
- Max. Wire Size 2 AWG
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 158 Degrees F
- Min. Operating Temp. -13 Degrees F
- Standards CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: BGA260601
- MPN: BGA260601
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121616
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 16
- UNSPSC Commodity Name: Molded case circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
