Circuit Breaker 45A 3P 525VAC BDA MPN:BDA34045Y
Circuit Breaker 45A 3P 525VAC BDA
Introducing our Circuit Breaker - an advanced solution designed for electrical protection in industrial control panels and commercial OEM settings. With a 45A rating and AC voltage of 525V, this breaker offers exceptional performance in handling high currents while minimizing electrical damage to connected devices. The molded case design enhances its durability, making it ideal for harsh environments. Its maximum AIR rating ensures reliable protection, making it suitable for a wide range of applications, including electrical distribution equipment. Upgrade your electrical system today with our high-quality Circuit Breaker and experience peace of mind knowing that your devices are secure.
Top product features:
- Molded Case Design: Offers durability and protection from harsh environments.
- AC Voltage Rating of 525V: Enables high-current handling and reliable performance.
- Maximum AIR rating of 25kA at 277/408V AC: Ensures robust protection for various applications.
Top product applications:
- Electrical Control Panels: To manage and regulate electrical power in industrial settings.
- Commercial OEM: For original equipment manufacturers to use in their devices and systems.
- Electrical Distribution Equipment: For protection against short circuits or overloads in distribution networks.
B-frame Square D molded case circuit breakers are rated up to 125A and interrupt excessive current flows to protect devices from electrical damage. They're used in industrial control panels, commercial OEM, electrical distribution equipment, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 45 A
- AC Voltage Rating 525V AC
- Max. AIR Rating 25kA at 277/408V AC
- For Use With Electrical Distribution Equipment, Industrial Control Panels
- Series BDA
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Al Mechanical Lug OFF End, I-Line ON End
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 125A/BD
- Circuit Breaker Mounting Style I-Line
- Height 5.39 in
- Width 3.19 in
- Depth 3.5 in
- Min. Wire Size 14 AWG
- Max. Wire Size 2 AWG
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 158 Degrees F
- Min. Operating Temp. -13 Degrees F
- Standards CSA C22.2 No 5, EN/IEC 60947-2, EN/IEC 60947-5-1, GB 14048.2, NEMA AB1, NMX J-266, UL 489
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: BDA34045Y
- MPN: BDA34045Y
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121616
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 16
- UNSPSC Commodity Name: Molded case circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
