Circuit Breaker 60A Bolt On 277/480V 3P MPN:EDB34060
Free Shipping
In Stock
Introducing the Circuit Breaker 60A Bolt On 277/480V 3P from Square D! These rugged circuit breakers are designed to provide dependable protection in commercial and industrial environments. With a sturdy bolted-on design, these circuit breakers offer increased stability compared to plug-in or unit-mount options. Their EBD and EGB series technology enables them to detect low-level faults and interrupt currents before they cause damage. The lug orientation of these circuit breakers allows for straight-in wiring through bus bars, eliminating the need for pigtailing wires and providing a clean, organized load center. These 60A Circuit Breakers are perfect for a wide range of applications, including use in panelboards, NF style distribution equipment, or as primary protection devices for motors, transformers, and other loads. Don't compromise on safety - invest in the durable and reliable Square D Circuit Breaker 60A Bolt On 277/480V 3P!
Top product features:
- Bolted-on design for increased stability compared to plug-in options.
- Interrupts currents when low-level faults are detected in the circuit.
- Lug orientation allows for straight-in wiring through bus bars, eliminating the need for pigtailing wires and helping organize the load center.
Top product applications:
- Use in commercial and industrial environments for electrical power distribution.
- Protect motors, transformers, and other electrical loads from overcurrent and short circuits.
- Improve load center organization by eliminating the need for pigtailing wires with lug orientation.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 60 A
- AC Voltage Rating 277/480V AC
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating 125/250V DC
- Circuit Breaker Actuator Toggle
- Circuit Breaker Mounting Style Bolt On
- Compatible Panelboard/Load Center Series NF
- Phase Three
- Series EDB
- Max. AIR Rating 18kA at 277/480V AC
- For Use With Square D NF Panelboards
- Terminal Connection Lug
- Frame Size 125A/EDB
- Length 5.66 in
- Width 2.94 in
- Depth 4.05 in
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size 2 AWG
- Standards cULus
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: EDB34060
- MPN: EDB34060
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
