Circuit Breaker 60A Bolt On 277V 1P MPN:EDB14060
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-cxg-3tw20
Circuit Breaker 60A Bolt On 277V 1P
The Square D Circuit Breaker 60A Bolt On 277V 1P is designed for installation in panelboards with NF panels. This reliable and stable circuit breaker is perfect for electrical professionals who require miniature circuit breakers that offer low-level fault detection, easy straight-in wiring, and elimination of pigtailing needs. With its 60A capacity and AC voltage rating of 277V, this standard circuit breaker with one pole can handle various applications in commercial and residential settings. Its rugged design ensures maximum performance even under heavy usage. Enhance your electrical system reliability and safety with Square D's circuit breakers.
Top product features:
- Interrupts currents for low-level fault detection
- Straight-in wiring through bus bars eliminates pigtailing needs
- Offers increased stability compared to plug-in or unit-mount circuit breakers
Top product applications:
- Commercial and residential electrical systems
- Low-level fault detection in wiring or equipment
- Bolt-on installation for panelboards with NF panels
These EBD and EGB series miniature circuit breakers are bolted into place in NF panelboards, so they're more stable than plug-in or unit-mount circuit breakers. They interrupt currents when low-level faults are detected in the circuit. They have a lug orientation to allow for straight-in wiring through bus bars, which eliminates the need to pigtail wires and helps organize the load center.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 60 A
- AC Voltage Rating 277V AC
- Circuit Breaker Type Standard
- Number of Poles 1
- DC Voltage Rating Not Rated
- Circuit Breaker Actuator Toggle
- Circuit Breaker Mounting Style Bolt On
- Compatible Panelboard/Load Center Series NF
- Phase Single
- Series EDB
- Max. AIR Rating 18kA at 120/240V AC
- For Use With Square D NF Panelboards
- Terminal Connection Lug
- Frame Size 125A/EDB
- Length 5.66 in
- Width 0.98 in
- Depth 4.05 in
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size 2 AWG
- Standards cULus, IEC
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: EDB14060
- MPN: EDB14060
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
