Circuit Breaker 350A 3P 240VAC Q4 MPN:Q4L3350

LA-, LH-, and Q4-frame Square D molded case circuit breakers are rated up to 400A and 600VAC and interrupt excessive current flows to protect devices from electrical damage. They're used in construction, control equipment panels, mining, and other industrial and commercial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.

Technical Specifications

• Item Molded Case Circuit Breaker
• Amps 350 A
• AC Voltage Rating 240V AC
• Max. AIR Rating 25kA at 120/240V AC
• For Use With Busway Plug-In Units, Combination Starters, Industrial Enclosures, Motor Control Centers, Panelboards, Switchboards
• Series Q4
• High Amp Trip Setting 3,500 A
• Low Amp Trip Setting 1,750 A
• Circuit Breaker Type Standard
• Number of Poles 3
• DC Voltage Rating Not Rated
• Terminal Connection Lug
• Trip Type Thermal Magnetic
• Phase 3
• Instantaneous Trip Adjustable
• Phase Connection ABC
• Frame Size 400A/Q4
• Circuit Breaker Mounting Style Free Standing
• Height 11.0 in
• Width 6.0 in
• Depth 5.84 in
• Min. Wire Size 1/0 AWG
• Max. Wire Size 250 MCM, 600 MCM
• Circuit Breaker Actuator Toggle
• Max. Operating Temp. 104 Degrees F
• Min. Operating Temp. 104 Degrees F
• Standards CSA, IEC, UL Listed

Manufacturer Details

• Manufacturer: Square D
• Condensed Mfg Number: Q4L3350
• MPN: Q4L3350

Label Details

• Hazardous Material: Y
• Green Material Flag: N
• Country of Origin: MX
• CA Prop 65 Wht Label: N

Classification Details

• Harmonization Code: 8536200020
• GDS Category Name: Molded Case Circuit Breakers
• GDS Family Name: Distribution
• GDS Segment Name: Electrical
• UNSPSC: 39121601
• UNSPSC Class ID: 16
• UNSPSC Commodity Name: Circuit protection devices and accessories
• UNSPSC Commodity ID: 01
• UNSPSC Commodity Name: Circuit breakers
• UNSPSC Family ID: 12
• UNSPSC Family Name: Electrical equipment and components and supplies
• UNSPSC Segment ID: 39
• UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

• Not For Sale In: HI AK PR
