Circuit Breaker 175A 3P 240VAC QD MPN:QDL32175
SKU
226-CXG-2JXG7
Circuit Breaker 175A 3P 240VAC QD
Square D molded case circuit breakers are ideal for protecting devices from electrical damage in commercial and industrial applications. With ratings up to 250A and 240VAC, these breakers can handle even the toughest jobs. Their compact design makes them easy to install, while their trip devices help prevent excessive current flows that can cause costly damages or fires. With a wide range of series options available, Square D circuit breakers are an essential tool for any OEM application that requires reliable protection and control.
Top product features:
- Rated up to 250A and 240VAC for heavy-duty applications
- Compact design for easy installation in tight spaces
- Trip devices to prevent excessive current flows and protect from damage
Top product applications:
- Protection against electrical overloads in commercial and industrial settings
- Use as a main or supplementary circuit breaker in home wiring systems
- Application in temporary power installations, construction sites, or events with high power consumption
Q-frame Square D molded case circuit breakers are rated up to 250A and 240VAC and interrupt excessive current flows to protect devices from electrical damage. They're used in OEM commercial and industrial applications. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 175 A
- AC Voltage Rating 240V AC
- Max. AIR Rating 25kA at 240V AC
- Series QD
- High Amp Trip Setting 2,400 A
- Low Amp Trip Setting 1,200 A
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Lug
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 250A/QD
- Circuit Breaker Mounting Style Free Standing
- Height 6.47 in
- Width 4.5 in
- Depth 3.93 in
- Min. Wire Size 4 AWG
- Max. Wire Size 300 MCM
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 104 Degrees F
- Standards CSA, IEC, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: QDL32175
- MPN: QDL32175
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
