Circuit Breaker 80A 3P 240VAC QD MPN:QDL32080
Free Shipping
In Stock
The Square D molded case circuit breaker is a reliable solution for protecting devices from electrical damage in commercial and industrial applications. Its 80A rating allows it to handle small to medium loads while its 240VAC voltage rating makes it suitable for a wide range of electrical systems. With a maximum interrupt rating of 25kA, this breaker is designed to quickly shut off power in case of overloads or short circuits, ensuring that your equipment stays safe and protected. The QD series provides easy installation and compact design, making it perfect for both new construction and retrofit projects. With its versatility, performance, and safety features, the Square D molded case circuit breaker is an ideal choice for any electrical system that requires reliable overcurrent protection.
Top product features:
- Q-frame design for easy installation and compactness in OEM commercial and industrial applications.
- Molded case contains current-carrying parts, mechanisms, and trip devices for reliable protection against electrical damage.
- Rated up to 250A and 240VAC to handle small to medium loads and provide versatility in use.
Top product applications:
- Protecting devices and systems in OEM commercial and industrial settings from electrical damage caused by overloads or short circuits.
- Safeguarding residential appliances or systems for extra protection during power surges or voltage fluctuations.
- Providing a reliable and convenient circuit protection solution in remodeling, retrofitting, or new construction projects.
Technical Specifications
- Item Molded Case Circuit Breaker
- Amps 80 A
- AC Voltage Rating 240V AC
- Max. AIR Rating 25kA at 240V AC
- Series QD
- High Amp Trip Setting 1,800 A
- Low Amp Trip Setting 1,000 A
- Circuit Breaker Type Standard
- Number of Poles 3
- DC Voltage Rating Not Rated
- Terminal Connection Lug
- Trip Type Thermal Magnetic
- Phase 3
- Instantaneous Trip Fixed
- Phase Connection ABC
- Frame Size 250A/QD
- Circuit Breaker Mounting Style Free Standing
- Height 6.47 in
- Width 4.5 in
- Depth 3.93 in
- Min. Wire Size 4 AWG
- Max. Wire Size 300 MCM
- Circuit Breaker Actuator Toggle
- Max. Operating Temp. 104 Degrees F
- Standards CSA, IEC, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: QDL32080
- MPN: QDL32080
Label Details
- Hazardous Material: Y
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Molded Case Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
