Circuit Breaker 20A Bolt On 277V 1P MPN:EDB14020EPD
Free Shipping
In Stock
The Circuit Breaker 20A Bolt On 277V 1P from Square D is designed for those looking for superior circuit protection in their panelboards. With their EBD and EGB series miniature circuit breakers, they provide exceptional stability and ground fault protection that meets NF standards. By bolting into place, these breakers offer a more secure fit compared to plug-in or unit-mount alternatives. The lug orientation enables straight-in wiring through bus bars, eliminating the need for pigtail wires and simplifying the load center organization. This makes it an ideal choice for a wide range of applications where high-quality circuit protection is required. Don't compromise on safety; invest in the Circuit Breaker 20A Bolt On 277V 1P from Square D today.
Top product features:
- Stability Provides stable and reliable circuit protection for panelboards compared to plug-in or unit-mount alternatives.
- Ground Fault Protection Detects low-level faults in circuits and interrupts currents to prevent potential hazards and damages.
- Straight-In Wiring Allows for easy wiring through bus bars without the need for pigtail wires, simplifying load center organization.
Top product applications:
- Industrial settings where circuit protection is critical, such as manufacturing plants or data centers.
- Commercial buildings that require stable and reliable electrical systems, including office spaces, schools, or hospitals.
- New installations or retrofits in NF panelboards that prioritize easy wiring, organization, and space efficiency.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 20 A
- AC Voltage Rating 277V AC
- Circuit Breaker Type Ground Fault Equipment Protection
- Number of Poles 1
- DC Voltage Rating Not Rated
- Circuit Breaker Actuator Toggle
- Circuit Breaker Mounting Style Bolt On
- Compatible Panelboard/Load Center Series NF
- Phase Single
- Series EDB
- Max. AIR Rating 18kA at 120/240V AC
- For Use With Square D NF Panelboards
- Terminal Connection Lug
- Frame Size 125A/EDB
- Length 6.64 in
- Width 1.96 in
- Depth 4.05 in
- Max. Operating Temp. 104 Degrees F
- Min. Wire Size 12 AWG (Al), 14 AWG (Cu)
- Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
- Standards cULus, IEC
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: EDB14020EPD
- MPN: EDB14020EPD
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
