Circuit Breaker 80A Plug In 120/240V 3P MPN:QO3801021
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-2GLY5
Circuit Breaker 80A Plug In 120/240V 3P
Introducing Square D's QO series miniature circuit breaker - the perfect solution for your home or commercial electrical needs! With a rating of 80A and compatible with both 120V and 240V systems, this versatile circuit breaker is designed to plug in easily into any NQOD or NQ load center without the need for bulky bolts. Its shunt trip mechanism ensures quick and reliable protection against low-level faults in your circuit, keeping you safe from electrical hazards. Plus, its connection to bus bars means no more cumbersome pigtail wires - just simple, streamlined installation. Whether you're a professional electrician or DIY enthusiast, the QO series miniature circuit breaker delivers ease of use and reliability in one convenient package.
Top product features:
- Plug-in design for easy installation
- Compatibility with both 120V and 240V systems
- Shunt trip mechanism for reliable overcurrent protection
Top product applications:
- Use in homes and small commercial spaces for electrical protection and power management
- Installation in existing panelboards or load centers without rewiring
- As a backup or supplementary circuit breaker for added safety in case of overcurrents
These QO series miniature circuit breakers plug into place in NQOD and NQ panelboards and QO load centers without requiring DIN rail or bolts, so they're easier to install than bolt-on and unit-mount breakers. They interrupt currents when low-level faults are detected in the circuit. They connect to the power supply through bus bars, which eliminates the need to pigtail wires and helps organize the panelboard or load center.
Technical Specifications
- Item Miniature Circuit Breaker
- Amps 80 A
- AC Voltage Rating 120/240V AC
- Circuit Breaker Type Shunt Trip
- Number of Poles 3
- DC Voltage Rating 48V DC
- Circuit Breaker Actuator Paddle
- Circuit Breaker Mounting Style Plug In
- Compatible Panelboard/Load Center Series QO
- Phase Three
- Series QO
- Max. AIR Rating 10kA at 120/240V AC
- For Use With QO Load Centers and NQ Panelboards
- Terminal Connection Lug
- Frame Size 100A/QO
- Length 3.5 in
- Width 3 in
- Depth 2.91 in
- Min. Wire Size 4 AWG
- Max. Wire Size 2 AWG
- Standards CSA Certified, UL Listed
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: QO3801021
- MPN: QO3801021
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8536200020
- GDS Category Name: Miniature Circuit Breakers
- GDS Family Name: Distribution
- GDS Segment Name: Electrical
- UNSPSC: 39121601
- UNSPSC Class ID: 16
- UNSPSC Commodity Name: Circuit protection devices and accessories
- UNSPSC Commodity ID: 01
- UNSPSC Commodity Name: Circuit breakers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
