Circuit Breaker 200A Plug In 120/240V 2P MPN:HOM2200

Discount: See in Cart
Free Shipping
In Stock
Brand: Square D
Part #: HOM2200
UPC: 785901065883
SKU
226-CXG-22P066
$335.49
Add to Wish List Add to Compare
Circuit Breaker 200A Plug In 120/240V 2P

The Circuit Breaker 200A Plug In 120/240V 2P from Square D is a convenient and easy-to-install miniature circuit breaker that offers efficient protection against low-level faults in electrical circuits. Its ability to plug into Homeline load centers eliminates the need for additional installation components, making it ideal for DIY enthusiasts and professional installers alike. With a rating of 200 Amp and compatible with 120/240V AC power supplies, this circuit breaker is suitable for a variety of residential and light-duty commercial applications. Its plug-in design offers easy accessibility and convenience, ensuring that the safety of your electrical system is always within reach. Upgrade to Square D's Circuit Breaker 200A Plug In 120/240V 2P today and enjoy added peace of mind with its reliable circuit protection capabilities.

Top product features:

  • Easy to install: Plug-in design eliminates need for DIN rail or bolts
  • Low-level fault protection: Interrupts currents when low-level faults are detected
  • Organized power supply: Connects to the power supply through bus bars, which helps organize load center

Top product applications:

  • Homes: Used in residential circuits to protect against overloads and short circuits
  • Small Businesses: Suitable for commercial applications with limited space or lower power demands
  • Remodeling Projects: Perfect for adding additional circuit protection during home renovations
These HOM series miniature circuit breakers plug into place in Homeline load centers without requiring DIN rail or bolts, so they're easier to install than unit-mount or bolt-on breakers. They interrupt currents when low-level faults are detected in the circuit. They connect to the power supply through bus bars, which eliminates the need to pigtail wires and helps organize the load center.

Technical Specifications

  • Item Miniature Circuit Breaker
  • Amps 200 A
  • AC Voltage Rating 120/240V AC
  • Circuit Breaker Type Standard
  • Number of Poles 2
  • DC Voltage Rating Not Rated
  • Circuit Breaker Actuator Paddle
  • Circuit Breaker Mounting Style Plug In
  • Compatible Panelboard/Load Center Series HOM
  • Phase Single
  • Series HOM
  • Max. AIR Rating 10kA at 120/240V AC
  • For Use With Homeline Load Center
  • Terminal Connection Lug
  • Frame Size 100A/HOM
  • Length 5.4 in
  • Width 4.0 in
  • Depth 3.0 in
  • Min. Operating Temp. 104 Degrees F
  • Max. Operating Temp. 104 Degrees F
  • Min. Wire Size 4 AWG
  • Max. Wire Size 300 MCM
  • Standards CSA Certified, HACR, UL Listed

Manufacturer Details

  • Manufacturer: Square D
  • Condensed Mfg Number: HOM2200
  • MPN: HOM2200

Label Details

  • Hazardous Material: N
  • Green Material Flag: N
  • Country of Origin: MX
  • CA Prop 65 Wht Label: N

Classification Details

  • Harmonization Code: 8536200020
  • GDS Category Name: Miniature Circuit Breakers
  • GDS Family Name: Distribution
  • GDS Segment Name: Electrical
  • UNSPSC: 39121601
  • UNSPSC Class ID: 16
  • UNSPSC Commodity Name: Circuit protection devices and accessories
  • UNSPSC Commodity ID: 01
  • UNSPSC Commodity Name: Circuit breakers
  • UNSPSC Family ID: 12
  • UNSPSC Family Name: Electrical equipment and components and supplies
  • UNSPSC Segment ID: 39
  • UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies

Shipping Details

  • Not For Sale In: HI AK PR
Related ASINs: B000H5QWSC
