Control Transformer 200VA 4.43 in H MPN:9070T200D13
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
226-CXG-1YUR7
Control Transformer 200VA 4.43 in H
Introducing the Square D Control Transformer - designed to meet your power needs for electrical control systems. With a high-efficiency vacuum impregnated varnish coating, this transformer is ideal for use with contactors, starters, solenoids, and relays that require a steady output voltage. Its low impedance windings ensure excellent voltage regulation, and it offers an output voltage range of 12V AC or 24V AC - making it perfect for a variety of applications. The compact size and lightweight design make it easy to install in any setting. Upgrade your electrical control system with the Square D Control Transformer today!
Top product features:
- Low impedance windings for excellent voltage regulation.
- Copper wound construction for durability and performance.
- Output voltage range of 12V AC or 24V AC for versatility.
Top product applications:
- Control panels and systems requiring constant voltage output.
- Use in security systems for door strikes or relays.
- Used in remote control devices such as garage door openers or gate operators.
Designed with low impedance windings for excellent voltage regulation, this transformer can accommodate the high inrush current associated with contactors, starters, solenoids, and relays. It is copper wound and vacuum impregnated with varnish.
Technical Specifications
- Item - Transformer Control Transformer
- Input Voltage - Transformer 120V AC
- Output Voltage - Transformer 12V AC, 24V AC
- VA Rating - Transformer 200 VA
- Protective Device None
- Enclosure Style - Transformer Open
- Mounting - Transformer Foot
- Phase - Electrical 1
- Hz - Electrical 50 Hz, 60 Hz
- Temp. Rise 80 Degrees C
- Enclosure Finish Epoxy Resin Varnish
- Height 4.43 in
- Depth 3.75 in
- Width 3.59 in
- Standards CE Compliant, CSA Certified, UL Listed
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Square D
- Condensed Mfg Number: 9070T200D13
- MPN: 9070T200D13
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: MX
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 8504314065
- GDS Category Name: Control Transformers
- GDS Family Name: Transformers
- GDS Segment Name: Electrical
- UNSPSC: 39121002
- UNSPSC Class ID: 10
- UNSPSC Commodity Name: Power conditioning equipment
- UNSPSC Commodity ID: 02
- UNSPSC Commodity Name: Power supply transformers
- UNSPSC Family ID: 12
- UNSPSC Family Name: Electrical equipment and components and supplies
- UNSPSC Segment ID: 39
- UNSPSC Segment Name: Electrical Systems and Lighting and Components and Accessories and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Related ASINs: B0078RL4QW
Product info last updated on November 17, 2023 12:17pm UTC Category: Transformers
