Disc Spring 1.188 Chrome Belleville PK10 MPN:B2437250
Disc Spring 1.188 Chrome Belleville PK10
Disc Spring 1.188 Chrome Belleville PK10 is a high-quality, precision disc spring manufactured from chrome alloy steel for use in heavy-duty applications. It features a square cross-section with precision-ground chamfered edges to reduce stress and increase load-bearing capacity. Its key specifications include an outer diameter of 1.063 inches, height of 0.875 inches, and spring rate of approximately 444 lbs/in. Disc Spring 1.188 Chrome Belleville PK10 is widely used in applications such as locking mechanisms, valve controls, punch dies, stampings, and vibration isolation devices to provide high-strength, low-cost solutions for spring design challenges.
Buy Spec item #B2437250 from our huge selection of Springs to show your support for our 🗽 Patriotic Veteran-Owned Business.
Technical Specifications
- Item Disc Spring
- Type Belleville Spring Washer
- Material Chrome
- Finish Plain
- Min. Inside Dia. 1.188 in
- Max. Outside Dia. 2.437 in
- Thickness 0.25 in
- Overall Height 0.278 in
- For Hole Size 2.437
- For Rod Size 1.188
- Load @ Deflection (Lbs.) 9635
- Deflection @ Load 0.022 in
- Calculated Load @ Flat (Lbs.) 13921
Manufacturer Details
- Manufacturer: Spec
- Condensed Mfg Number: B2437250
- MPN: B2437250
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: ZZ
- CA Prop 65 Wht Label: N
Classification Details
- Harmonization Code: 7318210090
- GDS Category Name: Disc Springs
- GDS Family Name: Springs
- GDS Segment Name: Hardware
- UNSPSC: 31161906
- UNSPSC Class ID: 19
- UNSPSC Commodity Name: Springs
- UNSPSC Commodity ID: 06
- UNSPSC Commodity Name: Disk springs
- UNSPSC Family ID: 16
- UNSPSC Family Name: Hardware
- UNSPSC Segment ID: 31
- UNSPSC Segment Name: Manufacturing Components and Supplies
Shipping Details
- Not For Sale In: HI AK PR
Product info last updated on June 10, 2023 12:44am UTC
Category: Springs
