D7964 Pressure Gauge 0 to 21 Bar 2-1/2In 1/4In MPN:LFS-210-21 BAR-G
This fluoroelastomer O-ring features a standard size of 30 inches inner diameter x 34 inches outer diameter and 2 inches thickness. It is widely used in various industrial applications as a sealant for liquid or gaseous materials due to its excellent resistance against temperature, chemicals, and mechanical forces. Its unique material composition enables it to withstand harsh conditions such as high temperatures (-45F to +300F) and pressure ranges (from vacuum up to 10,000 psi). Additionally, it offers a smooth surface finish that minimizes wear while providing consistent sealing performance. Due to its versatile properties, the fluoroelastomer O-ring is ideal for applications in automotive, aircraft, chemical processing, oil & gas exploration, and numerous other industries relying on reliable and long-lasting sealing solutions.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Copper
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units Bar
- Gauge Primary Range Values 0 to 21
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 0.2
- Gauge Case Material Zytel Nylon
- Gauge Primary Range Numbered Graduations 2
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass Alloy
- Basic Gauge Sensor Material Copper
- Gauge Sensor Material Copper Alloy
- Gauge Lens Material Polycarbonate
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included No
- Series LFS-210-BAR
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFS21021BARG
- MPN: LFS-210-21 BAR-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
