D7962 Pressure Gauge 0 to 6000 psi 2-1/2In MPN:LFS-210-6000-G-CERT
Our premium siding nail offers top-of-the-line performance for professionals working on outdoor construction projects, making it the perfect choice for building decks, fences, or installing siding. With a gauge size of 12 and an overall length of 2-1/2 inches, our product delivers superior holding power and durability in demanding applications. Its 8D head provides the ideal balance between depth of drive and ease of use, ensuring consistent performance and minimizing blow-throughs or withdrawals. The hot-dipped galvanized finish offers added protection against corrosion and rust, making it suitable for use in harsh environments and prolonging its lifespan. With its exceptional strength, our customers appreciate its ability to hold fast through various weather conditions, while maintaining its appearance and structural integrity over time.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Copper
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Bottom
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 6000
- Gauge Accuracy +/-1.00%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 100
- Gauge Case Material Zytel Nylon
- Gauge Primary Range Numbered Graduations 1000
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass Alloy
- Basic Gauge Sensor Material Copper
- Gauge Sensor Material Copper Alloy
- Gauge Lens Material Polycarbonate
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Calibration Certificate Included Yes, NIST with Data
- Series LFS-210
- Includes Pulsation Restrictor
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFS2106000GCERT
- MPN: LFS-210-6000-G-CERT
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
