Pressure Gauge 2-1/2 Dial Size MNPT MPN:LFC-224-2000-G
The Pressure Gauge - 2-1/2 Dial Size with MNPT features a liquid filled dial, 360 degrees angle rotations in vertical or horizontal positions to view easily from all angles, durable chrome plated case with stainless steel housing and comes complete with gasket and install. This gauge measures pressure ranging between vacuum-0 psig and 3000 psig making it ideal for monitoring various types of fluids such as air, hydraulic, pneumatic or water within commercial industrial and process industries where an accurate measurement is essential. Its large dial diameter display enhances readability from distance making it simple to operate even in dim lighting conditions. With its built-in diaphragm seal protection against corrosive fluids damaging internal gauge parts, this durable pressure gauges serves reliably day after day ensuring cost effective, accurate and precise measurements every time. The Pressure Gauge is suitable for use in diverse industrial applications like plant maintenance shops, machine shops or lab facilities where a consistent measuring tool with high dependability is vital.
Technical Specifications
- Item Pressure Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units psi
- Gauge Primary Range Values 0 to 2000
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Pressure Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 20
- Gauge Case Material ABS Plastic
- Gauge Primary Range Numbered Graduations 200
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Acrylic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Required Gauge Adapter 1 yr
- Characteristics With Brass Internals
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series LFC-224
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFC2242000G
- MPN: LFC-224-2000-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
