Compound Gauge 2-1/2 Dial Size MNPT MPN:LFC-220-3030-G
Compound Gauge 2-1/2 Dial Size MNPT
This compact gauge comes with a dial size of 2-1/2 inches, ideal for reading measurements accurately and effortlessly even in low light environments. It features an accurate pressure range from 0-1500 PSI, catering to various industrial applications that require precise pressure readings. With MNPT threads, it connects securely and efficiently, while its stainless steel construction ensures durability against harsh conditions. Typical users include technicians, engineers or mechanics looking for a reliable and user-friendly gauge in manufacturing, processing, testing or maintenance facilities.
This gauge is designed for use with air and fluids such as water and oil in pumps, filters, compressors, and regulators.
Technical Specifications
- Item Compound Gauge
- Gauge Application General Purpose
- Gauge Nominal Dial Size 2 1/2 in
- Basic Gauge Case Material Plastic
- Basic Gauge Wetted Parts Brass / Bronze
- Gauge Connection Type MNPT
- Gauge Connection Size 1/4 in
- Gauge Connection Location Center Back
- Gauge Primary Range Units in Hg/psi
- Gauge Primary Range Values -30 to 0 to 30
- Gauge Accuracy +/-3-2-3%
- Pressure and Vacuum Gauge Type Compound Gauge
- Gauge Panel Mountable No
- Liquid Filled Yes
- Gauge Primary Range Smallest Graduation 2/1
- Gauge Case Material ABS Plastic
- Gauge Primary Range Numbered Graduations 10/5
- Gauge Case Color Black
- Basic Gauge Socket Material Brass
- Gauge Socket Material Brass
- Basic Gauge Sensor Material Bronze
- Gauge Sensor Material Bronze
- Gauge Lens Material Acrylic
- Gauge Filled With Glycerin
- Basic Gauge Lens Material Plastic
- Operating Temp. Range -40 Degrees to 150 Degrees F
- Gauge Special Options Heavy Duty
- Required Gauge Adapter 1 yr
- Characteristics With Brass Internals
- For Use With Media Compatible with Bronze
- Calibration Certificate Included No
- Series LFC-220
- Manufacturers Warranty Length 1 yr
Manufacturer Details
- Manufacturer: Span
- Condensed Mfg Number: LFC2203030G
- MPN: LFC-220-3030-G
Label Details
- Hazardous Material: N
- Green Material Flag: N
- Country of Origin: US
- CA Prop 65 Wht Label: Y
- CA Prop 65 Warning Msg Scenario: 7
Classification Details
- Harmonization Code: 9026208000
- GDS Category Name: Commercial Industrial and Process Dial Pressure G
- GDS Family Name: Pressure and Vacuum Measuring
- GDS Segment Name: Test Instruments
- UNSPSC: 41112403
- UNSPSC Class ID: 24
- UNSPSC Commodity Name: Pressure measuring and control instruments
- UNSPSC Commodity ID: 03
- UNSPSC Commodity Name: Pressure indicators
- UNSPSC Family ID: 11
- UNSPSC Family Name: Measuring and observing and testing instruments
- UNSPSC Segment ID: 41
- UNSPSC Segment Name: Laboratory and Measuring and Observing and Testing Equipment
Shipping Details
- Not For Sale In: HI AK PR
